Description

The B-LFP48-100E is composed of 16 UL-listed lithium iron phosphate cells with an actual voltage of 51.2V. It has an impressive 5.12 kWh battery capacity & is protected against over-voltage and short-circuits with IP23 protected shell. The protective circuit comprises independent thermal and current monitoring circuits with LED indicators showing the state of charge and abnormal conditions (over-voltage or deep discharge).

The B-LFP48-100 LiFePo4 battery is an expandable battery pack with a built-in BMS system, which can be combined into a rack storage system or used individually in a home solar system. B-LFP48-100 is a smart residential energy storage device that enables homeowners to store the electricity generated by the on-site solar system or grid for use as an emergency home backup battery. Although it is attractive as an emergency power supply device, B-LFP48-100 was designed from the ground up to provide homeowners with on-site solar energy systems with a way to extend the electricity generated during the day to night.

The built-in battery management system integrates with multilevel safety features including overcharge and deep discharge protection, voltage and temperature observation, over current protection, cell monitoring and balancing, and over-heat protection. This high-performance BSLBATT® Lithium Battery has a large power capacity, with a fast charging and continuous discharge power, providing 98% efficiency. The advanced Lithium Ferro Phosphate (LFP) technology operates a wider temperature range to deliver the most dependable performance. LFP has been proven to be one of the safest Lithium technologies in the industry and is manufactured to the highest standards.

Note: Includes 35mm2 Battery parallel connections inside the box.

Note2: BSL B-LFP48-100E LiFePO4 Batteries are compatible and recommended for use with SkyBox Off-Grid & Hybrid Cabinets.

Main Features:

Long Battery Life- This 48V 100Ah Lithium battery has a cycle life of over 6000 cycles @ 80% DOD and is designed to last 15-20 years.

High Compatibility- This BSL 5kWh battery is compatible with most 48V inverters on the market and is already listed with Victron, Studer inverters.

BMS Protection- Built-in intelligent battery management system can provide various protection functions for Powerwall battery to avoid property loss in advance.

UL Standard Battery Pack- BSL batteries are manufactured with automotive grade process, and the high quality module structure can provide longer life and stability for the battery.

DC Coupling- The BSL B-LFP48-100E is a DC coupled battery system that is more suitable for your upcoming solar system installation with higher conversion efficiency.

10-Year Warranty- To give you peace of mind that you're getting clean, sustainable energy, we're backing this server rack battery with a 10-year warranty.

Additional Features:

- 6000+ Cycle Life with a 10 Year Warranty

- 5.12kWh expandable up to 153.6kWh (Max. 30 parallel connections)

- No Heat Generation, Mitigation, Thermal Monitoring or Toxic Cooling

- No Thermal Runaway with Fire Propagation

- Non-Toxic & Non-Hazardous Cobalt-Free LFP Chemistry

- Fast Charge & Discharge Rates 1C Continuous up to 2C Peak

- 99% Efficiency Rate

- Built-In Safety BMS with Breaker On/Off Switch for Shipping & Installation

- Compatible with over 20 inverters including Victron & Deye

- Modular, Scalable & Proven Performance

- CEC Approved

Specifications

Specifications | BSL 48V 5.12kWh Rack Mount LiFePO4 Battery - B-LFP48-100E

Please see more details in the 'Data Sheets' tab.

Delivery

We don't hold the stock on hand but have a trusted supplier who will send this direct from their nearest warehouse to ensure you receive it as soon as possible.

Warranty

BSL 48V 5.12kWh Rack Mount LiFePO4 Battery - B-LFP48-100E Warranty Sheet

Data Sheets

BSL 48V 5.12kWh Rack Mount LiFePO4 Battery - B-LFP48-100E Specifications
